SPRING DETAILS
Physical Dimensions
Tolerances
Wire Diameter (WD)
0.038 in mm
+/- 0.0006
Outer Diameter (OD)
0.500 in mm
+/- 0.008
Inner Diameter (ID)
0.424 in mm
+/- 0.008
Free Length (FL)
1.000 in mm
+/- 0.025
Active Coils (AC)
4.000
+/- 1/4 Coil
Total Coils (TC)
6.000
+/- 1/4 Coil
Solid Height (SH)
0.266 in mm
+/- 0.019
End Type (ET)
Closed End
...
Material Type (MT)
Music Wire
...
Spring Index (SI)
12.158
...
Spring Rate (RT)
7.594 lbs/in N/mm
+/- 10%
Max Load (MLD)
5.574 lbf N
+/- 10%
Max Travel (MDT)
0.734 in mm
+/- 10%
Wind direction (DW)
Right
...
Wire Diameter (WD)
0.037 in mm
+/- 0.0006
Outer Diameter (OD)
0.500 in mm
+/- 0.008
Inner Diameter (ID)
0.426 in mm
+/- 0.008
Length Inside Hook (LIH)
3.000 in mm
+/- 0.1
Body Length (BL)
2.361 in mm
+/- 0.1
Hook Length 1 (HL1)
0.320 in mm
...
Hook Length 2 (HL2)
0.320 in mm
...
Total Coils (TC)
62.811
+/- 1/4 Coil
Hook Type (ET)
Machine Hook
...
Material Type (MT)
Music Wire
...
Spring Index (SI)
12.514
...
Spring Rate (RT)
0.432 lbs/in N/mm
+/- 10%
Initial Tension (IT)
0.003 lbf N
+/- 10%
Max Load (MLD)
4.771 lbf N
+/- 10%
Max Travel (MDT)
11.042 in mm
+/- 10%
Wind direction (DW)
Right
...
Wire Diameter (WD)
0.030 in mm
+/- 0.0006
Outer Diameter (OD)
0.395 in mm
+/- 0.008
Inner Diameter (ID)
0.335 in mm
+/- 0.008
Body Length (BL)
0.180 in mm
+/- 0.015
Length Of Leg 1 (L1)
0.750 in mm
+/- 0.04
Length Of Leg 2 (L2)
0.750 in mm
+/- 0.04
Total Coils (TC)
5.000
+/- 1/8 Coil
Material Type (MT)
Music Wire
...
Spring Index (SI)
12.167
...
Free position (FP)
0.000
...
Spring Rate (RT)
0.003 in-lbs/Deg N-mm/Deg
+/- 10%
Max Load (MLD)
0.607 in-lbs N-mm
+/- 10%
Max Travel (MDT)
180.014 Deg Deg
+/- 10%
Wind direction (DW)
Right
...
